Terminal Aerodrome Forecast (TAF) Weather Decoder

Terminal aerodrome forecast decoders, crosswind resolution vectors, and density altitude calculations.

Interactive TAF Weather & Flight Dynamics Utility

P1 Flight Operations Suite

Aeronautical Calculators & Telemetry Envelopes

Crosswind Vector 10.0 kts
Headwind / Tailwind Vector 17.3 kts Headwind
Wind Angle Offset (Δθ) 30°
Pressure Altitude (PA) 2,500 ft
Density Altitude (DA) 4,894 ft
ISA Temperature Deviation +20.0°C
High Density Altitude (4,894 ft): Severe engine thrust degradation, prolonged takeoff roll, and reduced climb gradient.
Supported format: ICAO string with wind vector (e.g. 31015G25KT).
Parsed Wind Direction 310°
Sustained Wind Speed 15 kts
Peak Gust Velocity 25 kts
Aviation weather radar and terminal aerodrome forecast telemetry map
Terminal aerodrome meteorological radar and runway vector alignment telemetry.

Step-by-Step Adds Taf Specifications & Technical Metrics

The Taf Specifications, Interactive Tools & Guides reference provides verified technical specifications, payload-range envelopes, and interactive comparison tools for adds taf. Evaluate engine thrust, dimensional clearances, and operating limits with complete empirical rigor.

International commercial dispatch requires continuous evaluation of aerodrome operating minima. A standard international TAF covers a 24-hour or 30-hour validity window, updated routinely every six hours at 0000Z, 0600Z, 1200Z, and 1800Z. Dispatchers cross-reference forecast cloud base ceilings and Runway Visual Range (RVR) values against certified Category I, Category II, and Category III ILS instrument approach minimums.

Decoding the wind group (such as 28022G35KT) provides the basis for runway selection and crosswind computation. When runway magnetic heading is 310° and surface wind is reported as 280° at 22 knots with gusts to 35 knots, the angular difference is 30°. Resolving the vector yields a steady headwind of 19.1 knots with an 11.0-knot crosswind component, escalating to a 17.5-knot crosswind under peak 35-knot gusts.

Meteorological Telemetry Architecture

METAR Surface Observations vs TAF Terminal Forecasts

Operational distinctions between instantaneous surface sensor telemetry and predictive aerodrome forecast horizons.

Routine Aerodrome Report

METAR Observation Telemetry

Standardized alphanumeric surface weather observation updated hourly or half-hourly, recording current wind velocity, runway visual range, and cloud ceiling.

Update Frequency 30 – 60 minutes
Observation Validity Current Instantaneous
Wind Sampling Period 10-minute mean
Pressure Reporting QNH (hPa or inHg)
  • Direct runway sensor integration (AWOS / ASOS)
  • SPECI triggers for rapid meteorological deterioration
  • Mandatory international flight dispatch benchmark
24h / 30h Predictive Horizon

TAF Aerodrome Terminal Forecast

Certified meteorological prediction covering an aerodrome's operational area within 5 nautical miles, projecting wind shear, cloud ceiling, and trend groups.

Forecast Validity 24 – 30 hours
Issuance Schedule Every 6 hours (00/06/12/18Z)
Spatial Coverage 5 NM aerodrome radius
Change Groups TEMPO, BECMG, FM, PROB
  • Required for alternate airport dispatch selection
  • Predictive low-level wind shear alerts (WS)
  • Complies with ICAO Annex 3 & WMO No. 49 protocols

High-temperature operations further necessitate immediate density altitude calculations. High ambient field temperatures reduce air density, diminishing aerodynamic wing lift and degrading turbofan mass airflow. At an aerodrome elevation of 2,000 feet with an altimeter setting of 29.42 inHg and an outside air temperature of 30°C, the density altitude rises to 4,894 feet, demanding takeoff gross weight offloading or derated thrust recalculations.


Barometric pressure altimetry requires precise baseline calibration using local QNH values. In standard atmosphere conditions (29.92 inHg / 1013.25 hPa), pressure altitude equals true altitude. In low-pressure meteorological depressions, the altimeter over-reads actual physical height above terrain, necessitating strict temperature and altimeter correction procedures during cold-weather non-precision approaches.

MATHEMATICAL MODEL ICAO Annex 14 — Aerodromes (Volume I Aerodrome Design and Operations)

Runway Crosswind & Headwind Trigonometric Vector Decomposition

Vcross = Vwind × sin(Δθ), Vhead = Vwind × cos(Δθ)

Variable Definition & Units

V_{wind}
Wind Velocity (kts)

Reported sustained surface wind velocity or gust speed in knots

Δθ
Angular Offset (|Wind - Runway|)

Absolute angular difference between magnetic runway heading and wind direction

V_{cross}
Crosswind Component

Perpendicular lateral wind vector acting against aircraft directional control

V_{head}
Headwind / Tailwind Vector

Parallel longitudinal wind vector (negative values indicate tailwind conditions)

Interactive Taf Specification Explorer & Comparison Tool

Certified commercial dispatch relies on standardized celestial dome division into eight equal segments called oktas. Under ICAO Annex 3 and WMO No. 49 guidelines, an official aviation ceiling is established only when cloud layers cover more than four oktas (Broken or Overcast). Scattered (SCT) or Few (FEW) layers do not restrict instrument approaches as certified ceiling bases.

ICAO Annex 3 Alphanumeric Sky Coverage Classifications & Ceiling Standards
METAR / TAF Code Sky Coverage (Oktas) Aviation Ceiling Status Commercial Dispatch Impact
SKC / CLR 0 oktas (0%) No Ceiling (Clear Sky) Unrestricted visual approaches; standard visual flight rules (VFR) operating minimums apply.
FEW 1 to 2 oktas (12.5% – 25%) Not a Certified Ceiling Scattered daylight illumination; does not restrict Category I ILS precision descent procedures.
SCT 3 to 4 oktas (37.5% – 50%) Not a Certified Ceiling Partial celestial dome occlusion; pilot visual contact maintained during intermediate approach.
BKN 5 to 7 oktas (62.5% – 87.5%) Certified Aviation Ceiling Constitutes an official ceiling under ICAO Annex 3; determines destination and alternate landing minimums.
OVC 8 oktas (100%) Certified Aviation Ceiling Total sky obscuration; requires instrument flight rules (IFR) and precision instrument landing system approach.
VV Vertical Visibility Indefinite Surface Ceiling Reported in surface fog or heavy snow (e.g. VV002 = 200 ft); triggers low-visibility Category II/III autoland procedures.
Entry #1 SKC / CLR
Sky Coverage (Oktas) 0 oktas (0%)
Aviation Ceiling Status No Ceiling (Clear Sky)
Commercial Dispatch Impact Unrestricted visual approaches; standard visual flight rules (VFR) operating minimums apply.
Entry #2 FEW
Sky Coverage (Oktas) 1 to 2 oktas (12.5% – 25%)
Aviation Ceiling Status Not a Certified Ceiling
Commercial Dispatch Impact Scattered daylight illumination; does not restrict Category I ILS precision descent procedures.
Entry #3 SCT
Sky Coverage (Oktas) 3 to 4 oktas (37.5% – 50%)
Aviation Ceiling Status Not a Certified Ceiling
Commercial Dispatch Impact Partial celestial dome occlusion; pilot visual contact maintained during intermediate approach.
Entry #4 BKN
Sky Coverage (Oktas) 5 to 7 oktas (62.5% – 87.5%)
Aviation Ceiling Status Certified Aviation Ceiling
Commercial Dispatch Impact Constitutes an official ceiling under ICAO Annex 3; determines destination and alternate landing minimums.
Entry #5 OVC
Sky Coverage (Oktas) 8 oktas (100%)
Aviation Ceiling Status Certified Aviation Ceiling
Commercial Dispatch Impact Total sky obscuration; requires instrument flight rules (IFR) and precision instrument landing system approach.
Entry #6 VV
Sky Coverage (Oktas) Vertical Visibility
Aviation Ceiling Status Indefinite Surface Ceiling
Commercial Dispatch Impact Reported in surface fog or heavy snow (e.g. VV002 = 200 ft); triggers low-visibility Category II/III autoland procedures.

When fog, blowing snow, or volcanic ash obscures the sky dome such that cloud layers cannot be distinguished, automated observation stations report Vertical Visibility (VV) in hundreds of feet (e.g., VV002 denotes 200 feet vertical visibility into an indefinite ceiling). Flight crews operating under low-visibility procedures (LVP) must verify runway lighting intensity and dual-channel ILS localizer status prior to commencing approach below decision height.


Trend groups such as BECMG (becoming) and TEMPO (temporary) provide critical temporal precision. BECMG denotes a permanent meteorological transition taking place over a period not exceeding two hours. Conversely, TEMPO indicates short-lived fluctuations lasting less than 60 minutes per occurrence, allowing dispatchers to evaluate alternate airport fuel reserves without disqualifying primary destination availability.

Critical Aerodynamic Benchmarks & Operational Flight Limits

Runway surface friction and contamination condition codes (RWYCC 1 through 6) dictate maximum allowable crosswind limits. Flight manuals define strict limitations ranging from 38 knots on dry grooved concrete down to 10 knots on wet ice or standing water exceeding 3 mm in depth.


The Global Reporting Format (GRF) assesses Runway Condition Assessment Matrices (RCAM) using normalized decelerometer measurements. When temperatures drop below 0°C with compacted snow (RWYCC 3), directional control margins deteriorate under aerodynamic rudder slipstream shadowing during low-speed rollout.

Microburst wind shear detection systems (LLWAS and TDWR) monitor abrupt divergent horizontal wind shifts exceeding 30 knots within 3 nautical miles of the runway threshold. Flight crews receiving predictive wind shear alerts execute mandatory immediate go-around maneuvers with maximum takeoff thrust.

Performance Calculations, Dispatch Tolerances & Common Operational Traps

Neglecting to factor gust spreads (e.g. 15 knots sustained gusting to 25 knots) into approach speed additive increments (Vref + 50% gust spread) exposes flight crews to aerodynamic stall risks or runway overrun conditions during flare. Modern autoland systems disengage when crosswind components exceed certified dual-autopilot structural roll tolerances.


Furthermore, pressure altitude deviations during non-standard barometric conditions alter true airspeed. In cold-temperature operations below -15°C, true altitudes are substantially lower than indicated barometric altitudes, requiring mandatory altimeter temperature error corrections to published Minimum Sector Altitudes (MSA) and decision heights.

Dispatcher alternate selection rules under FAA 1-2-3 (1 hour before to 1 hour after ETA, ceiling less than 2,000 ft, visibility less than 3 statute miles) require continuous tracking of TAF trend indicators. When alternate aerodromes report marginal conditions, flight plans mandate carrying 45 minutes of reserve fuel at normal cruise consumption beyond the furthest designated alternate.

Engineering Integrity & Verification

Automated Flight Dynamics Unit Test Verification Harness

Zero-dependency in-browser unit tests verifying PRD Section 3 mathematical test fixtures.

8/8 PASSED 0.4ms

Frequently Asked Questions About Terminal Aerodrome Forecasts (TAF)

Frequently Asked Questions About Taf

Terminal Aerodrome Forecasts (TAF) provide certified weather predictions for an aerodrome's operational area, covering surface wind velocity, horizontal visibility, weather phenomena, and cloud base ceiling heights according to ICAO Annex 3 and WMO No. 49 standards.

What defines an official aviation ceiling in METAR and TAF reports?

Under ICAO Annex 3 and FAA standards, a ceiling is defined as the height above the earth's surface of the lowest layer of clouds or obscuring phenomena that is reported as Broken (BKN, 5/8 to 7/8 coverage), Overcast (OVC, 8/8 coverage), or Vertical Visibility (VV) into an indefinite ceiling.

What is the operational distinction between TEMPO and BECMG change indicators in a TAF?

TEMPO denotes temporary fluctuations in meteorological conditions expected to last less than 60 minutes in each instance and collectively cover less than half of the forecast period. BECMG describes a gradual transition where atmospheric conditions change steadily from one state to another over a specified time window (typically 2 hours).

```
